The product is equipped with an advanced control system and communication module, supporting functions such as intelligent scheduling, remote monitoring, and fault diagnosis. It supports connectivity with major mainstream electric car charging pile management platforms. Through connection to the cloud platform, operators can monitor the real-time operating status of the IP54 DC charging piles and perform remote maintenance and upgrades.
| Category | Specifications | Data Parameters |
|---|---|---|
| Appearance Structure | Dimensions (L x D x H) | 745mm x 630mm x 1750mm |
| Weight | 300kg | |
| Length of charging cable | 5m | |
| Connectors | CCS1 || CCS2 || CHAdeMO || GBT || NACS | |
| Electrical Indicators | Input Voltage | 400VAC / 480VAC (3P+N+PE) |
| Input frequency | 50/60Hz | |
| Output Voltage | 200 - 1000VDC (Constant power: 300 - 1000VDC) | |
| Output current (Air Cooled) | CCS1-200A || CCS2-200A || CHAdeMO-150A || GBT-250A || NACS-200A | |
| Output current (Liquid Cooled) | CCS2-500A || GBT-800A || GBT-600A || GBT-400A | |
| Rated Power | 40-240kW | |
| Efficiency | ≥94% at nominal output power | |
| Communication Protocol | OCPP 1.6J | |
| Functional Design | Display | 7'' LCD with touch screen |
| RFID system | ISO/IEC 14443A/B | |
| Access Control | RFID: ISO/IEC 14443A/B || Credit Card Reader (Optional) | |
| Communication | Ethernet (Standard) || 3G/4G || Wifi | |
| Cooling System | Air Cooled || Liquid Cooled | |
| Work Environment | Operating Temperature | -30°C to 55°C |
| Humidity | ≤ 95% RH (Operating) || ≤ 99% RH (Storage, Non-condensing) | |
| Altitude | < 2000m | |
| Ingress Protection | IP54 || IK10 | |
| Safety Design | Safety Standard | GB/T, CCS2, CCS1, CHAdeMO, NACS |
| Safety Protection | Overvoltage, lightning, overcurrent, leakage, waterproof protection, etc. | |
| Emergency Stop | Emergency Stop Button Disables Output Power |
